Sa 192 Boiler Fin Tube Supply For Superheater And Steam Pipeline
Material: SA 192
| Element | Composition |
| Carbon (C) | 0.06 - 0.18% |
| Manganese (Mn) | 0.27 - 0.63% |
| Phosphorus (P) | 0.035% max |
| Sulfur (S) | 0.035% max |
| Silicon (Si) | 0.10 - 0.35% |
| Copper (Cu) | 0.25% max |
Specification:
SA 192 is a seamless carbon steel boiler tube specification used in superheaters, heat exchangers, and condensers. It covers minimum-wall thickness, seamless cold-drawn low-carbon steel tubes for various applications in steam systems. These tubes are widely used in the manufacturing of boilers, boiler flues, superheater, and safe ends.
Mechanical Properties:
The mechanical properties of SA 192 boiler fin tubes are as follows:
| Property | Value |
| Tensile Strength | 325 MPa min |
| Yield Strength | 180 MPa min |
| Elongation | 35% min |
| Hardness (HRB) | 77 max |
Steel Grade:
SA 192 is classified under steel grade C, which indicates the minimum carbon content, ensuring excellent weldability and formability while maintaining strength and toughness.
Application:
Sa 192 Boiler Fin Tube Supply For Superheater And Steam Pipeline are specifically designed for applications in high-pressure and high-temperature environments. These tubes find extensive use in:
Boilers: SA 192 tubes are commonly used in boiler systems for their high thermal conductivity and resistance to corrosion, making them ideal for transferring heat efficiently.
Superheaters: In power generation systems, superheaters are employed to further increase the temperature of steam, enhancing the overall efficiency of the power plant. SA 192 tubes' ability to withstand high temperatures makes them well-suited for this purpose.
Heat Exchangers: Heat exchangers in various industries benefit from SA 192 tubes' excellent heat transfer properties, enabling efficient exchange of heat between two fluids.
Condensers: Condensers play a vital role in power plants, chemical processing plants, and refrigeration systems. SA 192 tubes provide reliable performance in these applications due to their robustness and resistance to corrosion.
