Products Description
Our Advantages
1. Strong Corrosion Resistance
Our Stainless Steel U Tubes are made of high-quality stainless steel, offering excellent resistance to oxidation, rust, and chemical corrosion, making them particularly suitable for chemical and marine environments.
Through chemical composition testing and salt spray testing, the pipes are guaranteed to withstand corrosion from chlorides, oxidants, and high temperatures.
2. High Temperature Resistance
Our pipes exhibit thermal stability, operating effectively at temperatures up to 900°C. They remain unaffected or deformed under thermal cycling, making them ideal for industries such as petrochemicals and aerospace.
3. High Pressure Resistance
Our pipes are seamless, manufactured using a cold-drawing process, eliminating weld seams and ensuring uniform overall mechanical strength. This makes them ideal for high-pressure systems such as heat exchangers, boilers, and chemical reactors.
4. Surface Quality
Our pipes undergo pickling, passivation, and polishing, resulting in a high-gloss surface finish that prevents the accumulation of scale, debris, or other particles, reducing the likelihood of pipe damage during use.
5. Quality Control
TORICH pipes undergo rigorous testing before entering the finished goods warehouse to ensure they meet JIS G3459 standards or customer requirements, and possess certifications such as PED, ATÜV, ISO 9001, ISO 14001, and CE.
6. Packaging and Transportation
Our pipes are packaged using plastic caps, plastic film, woven bags, and wooden crates to prevent damage or contamination during transportation. We offer various shipping options, including land, sea, and air freight, and samples are available.
application areas
- Gas turbines: Used in gas turbine blades and components.
- Power plant equipment: Commonly used in boiler tubes, superheaters, and heat exchangers in power plants.
- Furnaces and kilns: Suitable for use in industrial heating processes.
- Aerospace: Turbine engines and exhaust systems.
- Chemical process equipment: Commonly found in chemical reactors and industrial ovens in the petrochemical and pharmaceutical industries.
Chemical Composition
| Element | Carbon (C) | Manganese (Mn) | Chromium (Cr) | Nickel (Ni) | Silicon (Si) | Molybdenum (Mo) |
|---|---|---|---|---|---|---|
| SUS304TP | ≤ 0.08% | 2.00% – 2.50% | 18.00% – 20.00% | 8.00% – 10.50% | ≤ 1.00% | - |
| SUS304HTP | ≤ 0.08% | 2.00% – 2.50% | 18.00% – 20.00% | 8.00% – 10.50% | ≤ 1.00% | - |
| SUS310STP | ≤ 0.25% | 2.00% – 3.00% | 24.00% – 26.00% | 19.00% – 22.00% | ≤ 1.00% | - |
| SUS315J2TP | ≤ 0.10% | 1.50% – 2.50% | 25.00% – 28.00% | 20.00% – 23.00% | ≤ 1.00% | - |
Mechanical Properties
| Property | SUS304TP | SUS304HTP | SUS310STP | SUS315J2TP |
|---|---|---|---|---|
| Tensile Strength | ≥ 520 MPa | ≥ 550 MPa | ≥ 620 MPa | ≥ 700 MPa |
| Yield Strength | ≥ 215 MPa | ≥ 250 MPa | ≥ 250 MPa | ≥ 300 MPa |
| Elongation | ≥ 40% | ≥ 35% | ≥ 40% | ≥ 35% |
| Hardness | ≤ 201 HB | ≤ 220 HB | ≤ 201 HB | ≤ 240 HB |
| Modulus of Elasticity | ~200 GPa | ~200 GPa | ~200 GPa | ~200 GPa |
| Impact Toughness | ≥ 40 J | ≥ 45 J | ≥ 50 J | ≥ 50 J |
Possible Alternative Grades
| Alternative Grades | Reasons |
| AISI 317L | It exhibits extremely high corrosion resistance in sulfuric and chloride environments, making it suitable for chemical processing, marine and seawater pipelines. |
| AISI 904L | It performs well in high-temperature and corrosive chemical environments, making it suitable for marine applications requiring high resistance to seawater corrosion. |
| Duplex Stainless Steel | It possesses good weldability and formability, as well as superior resistance to stress corrosion cracking. |
Products Show
Testing Equipment
Factory Equipment
Pickling equipment
Products Package
