Products Description
Stainless Steel Sanitary Tubing ASTM A270 Tp304 TP316L
Advantages of Stainless Steel Sanitary Tubing ASTM A270 Tp304 TP316L
- In pharmaceutical and biotechnology applications, TP316L offers excellent resistance to pitting and crevice corrosion when exposed to chlorides or aggressive cleaning agents.
- In High-purity and chemical applications, TORICH tubing offers excellent resistance to a wide range of cleaning chemicals, disinfectants, and mild acids. The molybdenum content of TP316L gives it a distinct advantage over TP304 in chloride-rich or slightly acidic environments.
applications of Stainless Steel Sanitary Tubing ASTM A270 Tp304 TP316L
- Pharmaceutical and Biotechnology: High-purity water systems such as WFI (Water for Injection) and RO (Reverse Osmosis).
- High-purity and Chemical Processing: Handling mild chemicals, detergents, and sterilants, as well as applications requiring both hygienic and corrosion-resistant properties.
- Water Treatment and Filtration Systems: For ultrapure and deionized water distribution.
Chemical Composition
| Element | Carbon | Manganese | Silicon | Phosphorus | Sulfur | Chromium | Nickel | Molybdenum | Nitrogen | Ferrum |
| TP304 | ≤ 0.08 | ≤ 2.00 | ≤ 0.75 | ≤ 0.045 | ≤ 0.030 | 18.0 – 20.0 | 8.0 – 11.0 | – | ≤ 0.10 | Balance |
| TP316L | ≤ 0.035 | ≤ 2.00 | ≤ 0.75 | ≤ 0.045 | ≤ 0.030 | 16.0 – 18.0 | 10.0 – 14.0 | 2.0 – 3.0 | ≤ 0.10 | Balance |
Mechanical Properties
| Property | Tensile Strength | Yield Strength | Elongation | Hardness |
| TP304 | ≥ 515 MPa | ≥ 205 MPa | ≥ 40 (%) | ≤ 217 (HB) |
| TP316L | ≥ 485 MPa | ≥ 170 MPa | ≥ 40 (%) | ≤ 217 (HB) |
Possible Alternative Grades
- 304L: Lower carbon version of 304, improved weldability
- 316: Standard molybdenum-bearing grade with good corrosion resistance
- 317L: Higher molybdenum for stronger chemical resistance
- 321: Titanium-stabilized stainless steel for higher temperature resistance
- Duplex 2205: High strength and superior stress corrosion cracking resistance in chloride environments
Products Show
Products Application
Products Package
