ASTM A358 316 Welded Stainless Steel Pipe

ASTM A358 316 Welded Stainless Steel Pipe is an electric fusion-welded stainless steel pipe produced in accordance with ASTM A358 standard. It has excellent corrosion resistance, good mechanical properties, and wide applicability. It is commonly used in demanding industries such as petrochemical, chemical processing, and power generation.
Outer Diameter: 5mm-420mm (customizable)
Wall Thickness: 0.5mm-55mm (customizable)
Length: Can be customized upon request
Steel Grade:201 201LN XM-19 XM-29 304 304L 309S 309Cb 310S 310Cb 316 316L 317 317L 321 347

Products Description

ASTM A358 316 Welded Stainless Steel Pipe

Advantages of ASTM A358 316 Welded Stainless Steel Pipe

High Strength and Toughness: 316 Welded Stainless Steel Pipe offers excellent mechanical strength, capable of withstanding high pressures and loads. Its combination of toughness and formability makes it suitable for applications such as petroleum and petrochemical pipelines and high-pressure reactor vessels.
High and Low-Temperature Performance: 316 Welded Stainless Steel Pipe exhibits excellent high-temperature oxidation resistance and low-temperature resistance, making it suitable for boiler piping and heat exchangers.
Corrosion Resistance: 316 offers excellent resistance to chloride corrosion, making it ideal for seawater, marine, and saline applications.

applications of ASTM A358 316 Welded Stainless Steel Pipe

Chemical and petrochemical industries: Transport of acids, alkalis, solvents, and corrosive chemicals, as well as piping for reactors, condensers, and storage tanks.
Marine and offshore applications: Seawater cooling and piping systems, condensers, and heat exchangers.
Power generation: Power plant auxiliary piping, condenser and heat exchanger piping.
Industrial and manufacturing: Cooling and chemical transport in industrial plants.

Chemical Composition

Element	Carbon	Chromium	Nickel	Molybdenum	Niobium	Manganese	Phosphorus	Sulfur	Nitrogen
304L	0.03 max	18–20	8–12	-	-	2 max	0.045 max	0.03 max	0.1 max
309S	0.08 max	22–24	12–15	-	-	2 max	0.045 max	0.03 max	0.1 max
310Cb	0.08 max	24–26	19–22	-	0.5 min	2 max	0.045 max	0.03 max	0.1 max
316	0.08 max	16–18	10–14	2–3	-	2 max	0.045 max	0.03 max	0.1 max

Mechanical Properties

Property	Tensile Strength (MPa)	Yield Strength (MPa)	Elongation (%)	Hardness (HRB)
304L	485 min	170 min	40 min	92 max
309S	515 min	205 min	30 min	95 max
310Cb	515 min	205 min	30 min	95 max
316	485 min	170 min	40 min	92 max

Possible Alternative Grades

304, 316L, 317L: for improved corrosion resistance
321, 347: stabilized stainless steel for high-temperature service
904L: for high-corrosion industrial environments
Duplex stainless steels (2205, 2507): for chloride-rich and high-strength applications
